DG1209EUE+ Maxim LOW LEAKAGE, HIGH VOLTAGE DUEL 4
DG1209EUE+ Images
DG1209EUE+ Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • Description: LOW LEAKAGE, HIGH VOLTAGE DUEL 4
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
DG1209EUE+ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
DG1209EUE+ Specifications:
  • MfrPart.: DG1209EUE+
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: LOW LEAKAGE, HIGH VOLTAGE DUEL 4
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: -
  • Multiplexer/DemultiplexerCircuit: 4:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 160Ohm
  • Channel-to-ChannelMatching(ΔRon): 30Ohm
  • Voltage-SupplySingle(V+): 5V ~ 20V
  • Voltage-SupplyDual(V±): 5V ~ 20V
  • SwitchTime(TonToff)(Max): 400ns, 400ns
  • -3dbBandwidth: 250MHz
  • ChargeInjection: 0.5pC
  • ChannelCapacitance(CS(off)CD(off)): 15pF, 10pF
  • Current-Leakage(IS(off))(Max): 30µA
  • Crosstalk: -80dB @ 1MHz
  • OperatingTemperature: -40°C ~ 85°C
  • MountingType: Surface Mount
  • Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • DG1209EUE+ Maxim Integrated, LOW LEAKAGE, HIGH VOLTAGE DUEL 4, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG1209EUE+, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
