DG200ACJ Images
- Manufacturer: Maxim Integrated (Analog Devices, ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 14-DIP (0.300, 7.62mm)
- Description: IC SWITCH DUAL SPST 14DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG200ACJ Specifications:
- MfrPart.: DG200ACJ
- Mfr: Maxim Integrated (Now Part of Analog Devices)
- Description: IC SWITCH DUAL SPST 14DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 2
- On-StateResistance(Max): 80Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±4.5V ~ 18V
- SwitchTime(TonToff)(Max): 1µs, 500ns
- -3dbBandwidth: -
- ChargeInjection: 10pC
- ChannelCapacitance(CS(off)CD(off)): 9pF, 9pF
- Current-Leakage(IS(off))(Max): 2nA
- Crosstalk: -90dB @ 1MHz
- OperatingTemperature: 0°C ~ 70°C (TA)
- MountingType: Through Hole
- Package/Case: 14-DIP (0.300, 7.62mm)
- DG200ACJ Maxim Integrated, IC SWITCH DUAL SPST 14DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG200ACJ, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
