DG212EUE+T Images
- Manufacturer: Maxim Integrated (Analog Devices, ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- Description: IC SWITCH QUAD SPST 16TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG212EUE+T Specifications:
- MfrPart.: DG212EUE+T
- Mfr: Maxim Integrated (Now Part of Analog Devices)
- Description: IC SWITCH QUAD SPST 16TSSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 175Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±4.5V ~ 18V
- SwitchTime(TonToff)(Max): 1µs, 500ns
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 5pF, 5pF
- Current-Leakage(IS(off))(Max): 5nA
- Crosstalk: -90dB @ 100kHz
- OperatingTemperature: 0°C ~ 70°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- DG212EUE+T Maxim Integrated, IC SWITCH QUAD SPST 16TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG212EUE+T, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
