DG303AC/D Maxim TTL COMPATIBLE CMOS ANALOG SWITC
DG303AC/D Images
DG303AC/D Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: Die
  • Description: TTL COMPATIBLE CMOS ANALOG SWITC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
DG303AC/D Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
DG303AC/D Specifications:
  • MfrPart.: DG303AC/D
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: TTL COMPATIBLE CMOS ANALOG SWITC
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tray
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPDT
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 50Ohm
  • Channel-to-ChannelMatching(ΔRon): -
  • Voltage-SupplySingle(V+): ±5V ~ 18V
  • Voltage-SupplyDual(V±): ±5V ~ 18V
  • SwitchTime(TonToff)(Max): 300ns, 250ns
  • -3dbBandwidth: -
  • ChargeInjection: 12pC
  • ChannelCapacitance(CS(off)CD(off)): 14pF, 14pF
  • Current-Leakage(IS(off))(Max): 5nA
  • Crosstalk: -74dB @ 500kHz
  • OperatingTemperature: 0°C ~ 70°C (TA)
  • MountingType: Surface Mount
  • Package/Case: Die
  • DG303AC/D Maxim Integrated, TTL COMPATIBLE CMOS ANALOG SWITC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG303AC/D, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
