DG405CJ+ Maxim IC SWITCH DUAL DPST 16DIP
DG405CJ+ Images
DG405CJ+ Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
  • Description: IC SWITCH DUAL DPST 16DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
DG405CJ+ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
DG405CJ+ Specifications:
  • MfrPart.: DG405CJ+
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: IC SWITCH DUAL DPST 16DIP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: DPST - NO
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 45Ohm
  • Channel-to-ChannelMatching(ΔRon): 500mOhm
  • Voltage-SupplySingle(V+): 10V ~ 30V
  • Voltage-SupplyDual(V±): ±4.5V ~ 20V
  • SwitchTime(TonToff)(Max): 150ns, 100ns
  • -3dbBandwidth: -
  • ChargeInjection: 10pC
  • ChannelCapacitance(CS(off)CD(off)): 12pF, 12pF
  • Current-Leakage(IS(off))(Max): 500pA
  • Crosstalk: -90dB @ 1MHz
  • OperatingTemperature: 0°C ~ 70°C (TA)
  • MountingType: Through Hole
  • Package/Case: 16-DIP (0.300, 7.62mm)
  • DG405CJ+ Maxim Integrated, IC SWITCH DUAL DPST 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG405CJ+, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
