DG418CJ Maxim IC SWITCH SPST 8DIP
DG418CJ Images
DG418CJ Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 8-DIP (0.300, 7.62mm)
  • Description: IC SWITCH SPST 8DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
DG418CJ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
DG418CJ Specifications:
  • MfrPart.: DG418CJ
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: IC SWITCH SPST 8DIP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPST - NO
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 1
  • On-StateResistance(Max): 35Ohm
  • Channel-to-ChannelMatching(ΔRon): 3Ohm (Max)
  • Voltage-SupplySingle(V+): 10V ~ 30V
  • Voltage-SupplyDual(V±): ±4.5V ~ 20V
  • SwitchTime(TonToff)(Max): 175ns, 145ns
  • -3dbBandwidth: -
  • ChargeInjection: 3pC
  • ChannelCapacitance(CS(off)CD(off)): 8pF, 8pF
  • Current-Leakage(IS(off))(Max): 250pA
  • Crosstalk: -85dB @ 1MHz
  • OperatingTemperature: 0°C ~ 70°C (TA)
  • MountingType: Through Hole
  • Package/Case: 8-DIP (0.300, 7.62mm)
  • DG418CJ Maxim Integrated, IC SWITCH SPST 8DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG418CJ, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
