DG445DJ Images
- Manufacturer: Maxim Integrated (Analog Devices, ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC SWITCH QUAD SPST 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG445DJ Specifications:
- MfrPart.: DG445DJ
- Mfr: Maxim Integrated (Now Part of Analog Devices)
- Description: IC SWITCH QUAD SPST 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 85Ohm
- Channel-to-ChannelMatching(ΔRon): 4Ohm (Max)
- Voltage-SupplySingle(V+): 10V ~ 30V
- Voltage-SupplyDual(V±): ±4.5V ~ 20V
- SwitchTime(TonToff)(Max): 250ns, 170ns
- -3dbBandwidth: -
- ChargeInjection: 5pC
- ChannelCapacitance(CS(off)CD(off)): 4pF, 4pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -100dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- DG445DJ Maxim Integrated, IC SWITCH QUAD SPST 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG445DJ, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
