DG529DJ+ Images
- Manufacturer: Maxim Integrated (Analog Devices, ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 18-DIP (0.300, 7.62mm)
- Description: IC MULTIPLEXER DUAL 4X1 18DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG529DJ+ Specifications:
- MfrPart.: DG529DJ+
- Mfr: Maxim Integrated (Now Part of Analog Devices)
- Description: IC MULTIPLEXER DUAL 4X1 18DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 450Ohm
- Channel-to-ChannelMatching(ΔRon): 27Ohm
- Voltage-SupplySingle(V+): 5V ~ 30V
- Voltage-SupplyDual(V±): ±4.5V ~ 20V
- SwitchTime(TonToff)(Max): 1.5µs, 1.5µs
- -3dbBandwidth: -
- ChargeInjection: 4pC
- ChannelCapacitance(CS(off)CD(off)): 5pF, 25pF
- Current-Leakage(IS(off))(Max): 5nA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 18-DIP (0.300, 7.62mm)
- DG529DJ+ Maxim Integrated, IC MULTIPLEXER DUAL 4X1 18DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
