MAX14436FAWE+ Maxim DGTL ISO 5000VRMS 4CH GP 16SOIC
MAX14436FAWE+ Images
MAX14436FAWE+ Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Isolators~Digital Isolators Package/Case: 16-SOIC (0.295, 7.50mm Width)
  • Description: DGTL ISO 5000VRMS 4CH GP 16SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MAX14436FAWE+ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MAX14436FAWE+ Specifications:
  • MfrPart.: MAX14436FAWE+
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: DGTL ISO 5000VRMS 4CH GP 16SOIC
  • Product Category: Isolators~Digital Isolators
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • Technology: Capacitive Coupling
  • Type: General Purpose
  • IsolatedPower: No
  • NumberofChannels: 4
  • Inputs-Side1/Side2: 2/2
  • ChannelType: Unidirectional
  • Voltage-Isolation: 5000Vrms
  • CommonModeTransientImmunity(Min): 50kV/µs
  • DataRate: 200Mbps
  • PropagationDelaytpLH/tpHL(Max): 9.2ns, 9.4ns
  • PulseWidthDistortion(Max): 2ns
  • Rise/FallTime(Typ): 1.6ns, 1.4ns (Max)
  • Voltage-Supply: 1.71V ~ 5.5V
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Surface Mount
  • Package/Case: 16-SOIC (0.295, 7.50mm Width)
  • MAX14436FAWE+ Maxim Integrated, DGTL ISO 5000VRMS 4CH GP 16SOIC, Isolators~Digital Isolators
