MAX301ESE+T Maxim IC SWITCH DUAL SPST 16SOIC
MAX301ESE+T Images
MAX301ESE+T Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
  • Description: IC SWITCH DUAL SPST 16SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MAX301ESE+T Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MAX301ESE+T Specifications:
  • MfrPart.: MAX301ESE+T
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: IC SWITCH DUAL SPST 16SOIC
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tape & Reel (TR)
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SPST - NO
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 35Ohm
  • Channel-to-ChannelMatching(ΔRon): 500mOhm
  • Voltage-SupplySingle(V+): 10V ~ 30V
  • Voltage-SupplyDual(V±): ±4.5V ~ 20V
  • SwitchTime(TonToff)(Max): 150ns, 100ns
  • -3dbBandwidth: -
  • ChargeInjection: 10pC
  • ChannelCapacitance(CS(off)CD(off)): 12pF, 12pF
  • Current-Leakage(IS(off))(Max): 500pA
  • Crosstalk: -90dB @ 1MHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-SOIC (0.154, 3.90mm Width)
  • MAX301ESE+T Maxim Integrated, IC SWITCH DUAL SPST 16SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MAX301ESE+T, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
