MAX382EWN+ Maxim IC MUX 8CH DUAL 4CH 18SOIC
MAX382EWN+ Images
MAX382EWN+ Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 18-SOIC (0.295, 7.50mm Width)
  • Description: IC MUX 8CH DUAL 4CH 18SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MAX382EWN+ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MAX382EWN+ Specifications:
  • MfrPart.: MAX382EWN+
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: IC MUX 8CH DUAL 4CH 18SOIC
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: -
  • Multiplexer/DemultiplexerCircuit: 8:1
  • NumberofCircuits: 1
  • On-StateResistance(Max): 100Ohm
  • Channel-to-ChannelMatching(ΔRon): 4Ohm (Max)
  • Voltage-SupplySingle(V+): 2.7V ~ 16.5V
  • Voltage-SupplyDual(V±): ±2.7V ~ 8V
  • SwitchTime(TonToff)(Max): 150ns, 150ns
  • -3dbBandwidth: -
  • ChargeInjection: 2pC
  • ChannelCapacitance(CS(off)CD(off)): 11pF, 40pF
  • Current-Leakage(IS(off))(Max): 200pA
  • Crosstalk: -92dB @ 100kHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 18-SOIC (0.295, 7.50mm Width)
  • MAX382EWN+ Maxim Integrated, IC MUX 8CH DUAL 4CH 18SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MAX382EWN+, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
