MAX4533CPP Maxim SPDT ANALOG SWITCH
MAX4533CPP Images
MAX4533CPP Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 20-DIP (0.300, 7.62mm)
  • Description: SPDT ANALOG SWITCH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MAX4533CPP Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MAX4533CPP Specifications:
  • MfrPart.: MAX4533CPP
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: SPDT ANALOG SWITCH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPDT
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 175Ohm
  • Channel-to-ChannelMatching(ΔRon): 1Ohm
  • Voltage-SupplySingle(V+): 9V ~ 36V
  • Voltage-SupplyDual(V±): ±4.5V ~ 18V
  • SwitchTime(TonToff)(Max): 250ns, 150ns
  • -3dbBandwidth: -
  • ChargeInjection: 1.5pC
  • ChannelCapacitance(CS(off)CD(off)): 5pF
  • Current-Leakage(IS(off))(Max): 20nA
  • Crosstalk: -66dB @ 1MHz
  • OperatingTemperature: 0°C ~ 70°C (TA)
  • MountingType: Through Hole
  • Package/Case: 20-DIP (0.300, 7.62mm)
  • MAX4533CPP Maxim Integrated, SPDT ANALOG SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MAX4533CPP, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
