MAX4680CWE Images
- Manufacturer: Maxim Integrated (Analog Devices, ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: IC SWITCH DUAL SPST 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MAX4680CWE Specifications:
- MfrPart.: MAX4680CWE
- Mfr: Maxim Integrated (Now Part of Analog Devices)
- Description: IC SWITCH DUAL SPST 16SOIC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 2
- On-StateResistance(Max): 1.25Ohm
- Channel-to-ChannelMatching(ΔRon): 90mOhm
- Voltage-SupplySingle(V+): 4.5V ~ 36V
- Voltage-SupplyDual(V±): ±4.5V ~ 20V
- SwitchTime(TonToff)(Max): 275ns, 175ns
- -3dbBandwidth: -
- ChargeInjection: 55pC
- ChannelCapacitance(CS(off)CD(off)): 115pF, 115pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -65dB @ 1MHz
- OperatingTemperature: 0°C ~ 70°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- MAX4680CWE Maxim Integrated, IC SWITCH DUAL SPST 16SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MAX4680CWE, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
