MAX4749EUD+T Maxim IC SWITCH QUAD SPST 14TSSOP
MAX4749EUD+T Images
MAX4749EUD+T Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 14-TSSOP (0.173, 4.40mm Width)
  • Description: IC SWITCH QUAD SPST 14TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MAX4749EUD+T Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MAX4749EUD+T Specifications:
  • MfrPart.: MAX4749EUD+T
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: IC SWITCH QUAD SPST 14TSSOP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tape & Reel (TR)
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SPST - NO/NC
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 25Ohm
  • Channel-to-ChannelMatching(ΔRon): 100mOhm
  • Voltage-SupplySingle(V+): 2V ~ 11V
  • Voltage-SupplyDual(V±): -
  • SwitchTime(TonToff)(Max): 85ns, 45ns
  • -3dbBandwidth: 250MHz
  • ChargeInjection: 9pC
  • ChannelCapacitance(CS(off)CD(off)): 20pF, 20pF
  • Current-Leakage(IS(off))(Max): 100pA
  • Crosstalk: -84dB @ 1MHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 14-TSSOP (0.173, 4.40mm Width)
  • MAX4749EUD+T Maxim Integrated, IC SWITCH QUAD SPST 14TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MAX4749EUD+T, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
