MAX766CPA Images
- Manufacturer: Maxim Integrated (Analog Devices, ADI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators Package/Case: 8-DIP (0.300, 7.62mm)
- Description: IC REG BCK BST ADJ/-15V 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MAX766CPA Specifications:
- MfrPart.: MAX766CPA
- Mfr: Maxim Integrated (Now Part of Analog Devices)
- Description: IC REG BCK BST ADJ/-15V 8DIP
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
- Package: Tube
- Series: -
- PartStatus: Obsolete
- Function: Step-Up/Step-Down
- OutputConfiguration: Negative
- Topology: Buck-Boost
- OutputType: Adjustable (Fixed)
- NumberofOutputs: 1
- Voltage-Input(Min): 3V
- Voltage-Input(Max): 16V
- Voltage-Output(Min/Fixed): -1V (-15V)
- Voltage-Output(Max): -16V
- Current-Output: 105mA
- Frequency-Switching: 300kHz
- SynchronousRectifier: No
- OperatingTemperature: 0°C ~ 70°C (TA)
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- MAX766CPA Maxim Integrated, IC REG BCK BST ADJ/-15V 8DIP, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
MAX766CPA, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
