TSC426C/D Images
- Manufacturer: Maxim Integrated (Analog Devices, ADI)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: Die
- Description: IC GATE DRVR LOW-SIDE DIE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TSC426C/D Specifications:
- MfrPart.: TSC426C/D
- Mfr: Maxim Integrated (Now Part of Analog Devices)
- Description: IC GATE DRVR LOW-SIDE DIE
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- DrivenConfiguration: Low-Side
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: N-Channel, P-Channel MOSFET
- Voltage-Supply: 4.5V ~ 18V
- LogicVoltage-VILVIH: 0.8V, 2.4V
- Current-PeakOutput(SourceSink): 1.5A, 1.5A
- InputType: Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 25ns, 25ns
- OperatingTemperature: 0°C ~ 70°C
- MountingType: Surface Mount
- Package/Case: Die
- TSC426C/D Maxim Integrated, IC GATE DRVR LOW-SIDE DIE, Integrated Circuits (ICs)~PMIC - Gate Drivers
