TSC426CPA+ Maxim IC GATE DRVR LOW-SIDE 8DIP
TSC426CPA+ Images
TSC426CPA+ Images
  • Manufacturer: Maxim Integrated (Analog Devices, ADI)
  • Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-DIP (0.300, 7.62mm)
  • Description: IC GATE DRVR LOW-SIDE 8DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
TSC426CPA+ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
TSC426CPA+ Specifications:
  • MfrPart.: TSC426CPA+
  • Mfr: Maxim Integrated (Now Part of Analog Devices)
  • Description: IC GATE DRVR LOW-SIDE 8DIP
  • Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • DrivenConfiguration: Low-Side
  • ChannelType: Independent
  • NumberofDrivers: 2
  • GateType: N-Channel, P-Channel MOSFET
  • Voltage-Supply: 4.5V ~ 18V
  • LogicVoltage-VILVIH: 0.8V, 2.4V
  • Current-PeakOutput(SourceSink): 1.5A, 1.5A
  • InputType: Inverting
  • HighSideVoltage-Max(Bootstrap): -
  • Rise/FallTime(Typ): 25ns, 25ns
  • OperatingTemperature: 0°C ~ 70°C (TA)
  • MountingType: Through Hole
  • Package/Case: 8-DIP (0.300, 7.62mm)
  • TSC426CPA+ Maxim Integrated, IC GATE DRVR LOW-SIDE 8DIP, Integrated Circuits (ICs)~PMIC - Gate Drivers
TSC426CPA+, Maxim authentic parts in stock from Maxim Integrated authorized distributors, order today, can ship immediately.
